AA1570 - Thunderbolt™ 4 多功能桌面扩展基座
USB 5.1 Channel Audio Adapter
AA1570是一款功能强大的Thunderbolt™ 4桌面扩展基座,专为需要多设备连接、高速数据传输和强大供电能力的专业用户设计。它通过Thunderbolt™ 4接口提供40Gbps的超高速传输速率,支持多显示器和多设备的连接,提升工作效率和使用体验。
产品介绍
特性:
Thunderbolt™ 4 高速传输:支持高达40Gbps的数据传输速率,满足快速传输大文件和高效数据处理的需求。
双4K或单8K视频输出:支持双4K@60Hz或单8K@30Hz视频输出,适合高分辨率的多显示器设置,提升视觉体验。
96W供电能力:支持最高96W的笔记本充电,同时为其他设备提供稳定的电力供应。
多接口扩展:提供USB-C、USB-A、HDMI、以太网、SD卡槽等多种接口,满足不同设备的连接需求。
兼容多平台:支持Windows和MacOS系统,广泛适用于各种设备。
即插即用:无需安装驱动程序,支持热插拔,方便快速连接各种设备。
规格:
接口类型:Thunderbolt™ 4、USB-A、USB-C、HDMI、以太网、SD卡槽等
视频输出:支持双4K@60Hz或单8K@30Hz
数据传输速度:Thunderbolt™ 4接口支持高达40Gbps的传输速率
充电能力:支持最高96W的笔记本充电
尺寸:145 x 75 x 30mm
重量:350g
产品参数
参数名称 | 规格 |
---|---|
USB Upstream | 1x USB-B |
Audio-Out | Headphone: 1x3.5mm Stereo audio Jack Female in Green Front Audio: 1x3.5mm Stereo audio Jack Female in Green Surround: 1x3.5mm Stereo audio Jack Female in Gray Back Surround: 1x3.5mm Stereo audio Jack Female in Black Center/Subwoofer: 1x3.5mm Stereo audio Jack Female in Yellow S/PDIF-In: 1x S/PDIF Audio Jack Female in Black |
Audio-In | Line-In Port: 1x3.5mm Stereo audio Jack Female in Blue Mic-In Port: 1x3.5mm Stereo audio Jack Female in Pink S/PDIF-In: 1x S/PDIF Audio Jack Female in Black |
LED Indicators | Green: Lights up when powered on; flash when operation. Blue: Lights up for recording muted, lights off for recording function can be used |
HID Buttons | Volume Up: Press the Volume up bottom for volume up Volume Down: Press the Volume down bottom for volume down Play Mute: Press the Play Mute bottom for playback mute Record Mute: Press the Record Mute bottom for recording process mute |
Power Mode | Self-powered |
Sample Rate | Supports Fixed 48/44.1 KHz sampling rate in analog recording and playback |
Compliant | USB 1.1 and 2.0 full speed specification to 1.5/12 Mbps USB audio device class specification 1.0 USB HID class specification V1.1 EC 60958 spec. compliant (consumer format S/PDIF input and output with loop-back support) SCMS (Serial Copy Management System) |
